Direct acting solenoid valve for domestic RO based water purification
system |
| Domestic RO based water system uses water
solenoid valve to control feed and in membrane flushing.
Due to lower inlet pressure, pilot operated valves can not
give adequete flow. General Imsubs manufactures R series
valve which are direct actinng, wet armature type valve. |
|
|
|
|
 |
 |
Features |
-
Designed
& developed to meet harsh tropical demands.
-
Superior magnetic path for lower operating voltage.
-
Micro
polished wetted parts for corrosion resistance
and reduced scale accumulation.
-
Electroless nickle plated brass armature tube.
-
Leaded wire coil.
-
0
to 8 bar operating pressure.
|
|
Sr.No.
|
PARAMETER
|
DESCRIPTION
|
|
1.
|
Connector
|
Leaded wire
|
|
2.
|
Electric Rating
|
12 V DC / 24
V DC /
36 V DC / 48 V DC
|
|
3.
|
Current
|
6 VA
|
|
4.
|
Insulation Class
|
"B", 120° C.
|
|
6.
|
Solenoid Temperature Rise
|
Under 95° C. at 35° C.
ambient.
|
|
| Operating Parameter |
|
Sr. No. |
PARAMETER |
DESCRIPTION |
|
1. |
Suitable Fluid |
Water |
|
2. |
Ambient Temp. |
45° C. max. |
|
3. |
Fluid Temp. |
90° C max. |
|
4. |
Operating Pressure
|
0 to 8 bar |
|
5. |
Inlet / Outlet Connection
|
1/4" BSP / 1/8" BSP (Female
thread) |
|
7. |
Burst Pressure |
25 bar minimum. |
|
8. |
Water Leakage |
No leakage |
|
9. |
Orifice Size
|
2.5 / 3 mm |
|
10. |
Operating Rate |
100 % |
|
11. |
Life |
More than 50,000 cycles. |
|
|
