Compressed air saving is
very important as cost of compressed air is maximum when
compared with any other utilities. Considerable amount
of compressed air can be saved if GIPL AIR SAVING
PRODUCTS ARE USED
Parameter
Conventional blow method
eX Blow
Real Blow Nozzle / Pipe
Remarks
Orifice size
6 mm ø
N/A
N/A
Due to its air amplifying nature effective orifice size is much smaller than total air delivered
Air consumption @ 5 BarCFM (LPM)
70 (1982.17)
20 (566.33)
20 (566.33)
GIPL products meets international safety norms. Which are mandatory for ISO 14000
Air out put CFM (LPM)
70 (1982.17)
120 (3398.02)
240-500 (6796 to 14158)
For equivalent output of conventional blow method,
GIPL products consumes little compressed air
Compressed air cost considering 1 HP (0.75 kW)=4 CFM
and Rs. 4.00 / kWh
0.75X4=300 Ps. 300/(4 CFMX60)=1.25 Ps. / CF. Means
Rs. 52.50 per hour
0.75X4=300 Ps. 300/(4 CFMX60)=1.25 Ps. / CF. Means
Rs. 15 per hour
0.75X4=300 Ps. 300/(4 CFMX60)=1.25 Ps. / CF. Means
Rs. 15 per hour
As compressed air used by operator for personal
cleaning, wastage of compressed air for such
application is not taken into consideration.
Net Savings per Hour
Nil
Rs. 37.50
Rs. 37.50
For same given work, your organization saves every
minute – everyday
Pay Back period eX Blow Gun 34 Working hours
Pay Back period Real Blow Nozzle 9 Working hours
Pay Back period Real Blow Pipe 6 Working hours
Important:
1. Compressed user must keep in mind that compressed air cost about 1.25 paise per cu. Ft.
2. Prevent air leakage for economy.
3. Never blow from open pipes or conventional cheap blow guns, it is expensive and unsafe to operator. International safety norms does not permit blowing of air from such devices. And if you wish to obtain ISO 14000 than it is must.
4. Always use GIPL compressed air amplifying products to remain competitive.
5. For technical assistance contact general Imsubs or their business partners.
